FGK Series Sprag Clutch Bearing 72mm OD 50mm ID 460Nm Torque

Name: FGK Series Sprag Clutch Bearing 72mm OD 50mm ID 460Nm Torque
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: FGK dari kopling sprag satu arah
Price: 7.10 USD
Availability: InStock

Rincian produk

Tempat asal: Jiangsu, Cina

Nama merek: SUMA of one-way sprag clutch

Nomor model: FGK dari kopling sprag satu arah

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 1

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            72mm sprag clutch bearing, 50mm ID one way bearing, 460Nm torque sprag clutch


Peringkat presisi:	P6	Tipe Segel:	Membuka
Jenis:	Sprang	Diameter luar:	72mm
Diameter dalam:	50mm	Tinggi:	80mm
Bahan:	Baja Chrome GCR15	Torsi:	460nm
Kecepatan Max:	3400 min-1	Beban dinamis:	9650 n
Beban statis:	10000 n	Diameter bore:	50mm
Berat:	0,36kg	Torsi nominal:	460nm
Peringkat beban:	6950 n

Peringkat presisi:	P6
Tipe Segel:	Membuka
Jenis:	Sprang
Diameter luar:	72mm
Diameter dalam:	50mm
Tinggi:	80mm
Bahan:	Baja Chrome GCR15
Torsi:	460nm
Kecepatan Max:	3400 min-1
Beban dinamis:	9650 n
Beban statis:	10000 n
Diameter bore:	50mm
Berat:	0,36kg
Torsi nominal:	460nm
Peringkat beban:	6950 n

Deskripsi

FGK Series Sprag Clutch Bearing 72mm OD 50mm ID 460Nm Torque

FGK Series FGK20 FGK30 Freewheels One-Way Sprag Clutch Bearing

Product Description

The FGK Series sprag freewheels feature bearing support in the dimensions of needle bearing series 59.

Applications

Backstops
Overrunning Clutches
Indexing Freewheels

Technical Specifications

Size	Nominal Torque (Nm)	Max Speed (min^-1)	Load Rating (Dynamic)	Bore (mm)	D (mm)	K (mm)	L (mm)	Weight (kg)
FGK20	50	5,500	5,600	20	37	42	23	0.09
FGK25	70	5,300	6,300	25	42	48	23	0.11
FGK30	95	5,000	7,700	30	47	54	23	0.13
FGK35	200	4,600	8,200	35	55	63	27	0.20
FGK40	310	4,200	8,650	40	62	70	30	0.30
FGK45	370	3,800	9,200	45	68	76	30	0.34
FGK50	460	3,400	9,650	50	72	80	30	0.36

Product Images

Manufacturer Information

Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) specializes in manufacturing various cam clutches, one-way bearings, backstop clutches, and overrunning clutches with advanced technology.

We adhere to "Best Quality, Best Price, Fast Delivery, Best Service" to ensure customer satisfaction.

Production Process

Frequently Asked Questions

How do you pack the goods?

Total less than 25 KG: Each in white box + 19×18×9cm box + 29×28×19CM carton box
Total Weight over 100KG: Carton box + Wooden Box / Wooden Pallet

Can I get samples from you?

Samples are available for quality inspection and highly encouraged.

Can you promise timely delivery?

Small items: In stock
Medium Items: 10-15 Days
Big items: 20-25 Days
