FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

Name: FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: FGK 25
Price: 7.10 USD
Availability: InStock

Rincian produk

Tempat asal: Jiangsu, Cina

Nama merek: SUMA

Nomor model: FGK 25

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 1

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            25mm one way sprag bearing, 42mm OD one way bearing, 70Nm torque one way bearing


Peringkat presisi:	P6	Tipe Segel:	Membuka
Diameter luar:	42mm	Diameter dalam:	25mm
Tinggi:	48mm	Bahan:	Baja Chrome GCR15
Torsi:	70NM	Diameter bore:	25mm
Kapasitas torsi:	70NM	Kecepatan balapan batin:	530r/mnt
Kecepatan Balap Luar:	3800r/mnt	Beban dinamis:	6300n
Beban statis:	3450n	Berat:	0,11KG
Jenis:	Sprang

Peringkat presisi:	P6
Tipe Segel:	Membuka
Diameter luar:	42mm
Diameter dalam:	25mm
Tinggi:	48mm
Bahan:	Baja Chrome GCR15
Torsi:	70NM
Diameter bore:	25mm
Kapasitas torsi:	70NM
Kecepatan balapan batin:	530r/mnt
Kecepatan Balap Luar:	3800r/mnt
Beban dinamis:	6300n
Beban statis:	3450n
Berat:	0,11KG
Jenis:	Sprang

Deskripsi

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

FGK 25 Sprag Clutches Freewheels One Way Bearing FGK25

Product Description

Internal Freewheels FGK are sprag freewheels with bearing support in the dimensions of the needle bearing series 59.

Applications

Backstops
Overrunning Clutches
Indexing Freewheels

Specifications

Model	FGK25
Material	Gcr15
Bore diameter	25mm
Outer diameter	42mm
Height	48mm
Torque capacity	70Nm
Inner race overrun speed	530r/min
Outer race overrun speed	3800r/min
Application	Automobiles, motorcycles, power tools, textile machines
Package	Carton package / Wooden package
Delivery time	5-7 days
Payment terms	TT, L/C, D/P, D/A, Western Union, Paypal

Technical Specifications

Size	Nominal Torque (Nm)	Max. Speed (Inner/Outer)	Load Rating (Dynamic/Static)	Bore (mm)	D (mm)	K (mm)	L (mm)	Weight (kg)
FGK20	50	5,500/4,000	5,600/4,400	20	37	42	23	0.09
FGK25	70	5,300/3,800	6,300/5,300	25	42	48	23	0.11
FGK30	95	5,000/3,500	7,700/5,500	30	47	54	23	0.13
FGK35	200	4,600/3,200	8,200/8,500	35	55	63	27	0.20
FGK40	310	4,200/3,000	8,650/8,300	40	62	70	30	0.30
FGK45	370	3,800/2,500	9,200/9,650	45	68	76	30	0.34
FGK50	460	3,400/2,200	9,650/10,000	50	72	80	30	0.36
