CSK25 One Way Sprag Bearing 25x52x15mm 85Nm Washing Machine Clutch

Name: CSK25 One Way Sprag Bearing 25x52x15mm 85Nm Washing Machine Clutch
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: CSK25
Price: 1.80 USD
Availability: InStock

Rincian produk

Tempat asal: Jiangsu, Cina

Nama merek: SUMA

Nomor model: CSK25

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 10

Harga: $1.80-2

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            CSK25 one way sprag bearing, washing machine clutch bearing 25x52x15mm, 85Nm one way bearing with warranty


Peringkat presisi:	P0	Tipe Segel:	Tertutup
Jenis:	Sprang	Ukuran:	255215mm
Torsi:	85NM	Berat:	0,14kg
Bahan:	GCR15	Diameter dalam:	25mm
Diameter luar:	52mm	Kecepatan overrunning:	5200r/menit
Kapasitas torsi:	85NM	Beban dinamis:	10.7KN
Beban statis:	5.46kn	Torsi seret:	2ncm
Seri bantalan:	6205

Peringkat presisi:	P0
Tipe Segel:	Tertutup
Jenis:	Sprang
Ukuran:	255215mm
Torsi:	85NM
Berat:	0,14kg
Bahan:	GCR15
Diameter dalam:	25mm
Diameter luar:	52mm
Kecepatan overrunning:	5200r/menit
Kapasitas torsi:	85NM
Beban dinamis:	10.7KN
Beban statis:	5.46kn
Torsi seret:	2ncm
Seri bantalan:	6205

Deskripsi

CSK25 One Way Sprag Bearing 25x52x15mm 85Nm Washing Machine Clutch

CSK25 CSK6205 One Way Sprag Type Bearing Washing Machine Clutch Overrunning Clutch

Product Description

The CSK25 CSK6205 is a sprag type freewheel integrated into a 62 series ball bearing, designed specifically for washing machine clutch applications.

Key Features

Sprag type freewheel integrated with ball bearing (except sizes 8 and 40)
Available in size ranges from CSK 8-40mm to meet various application requirements
Delivered grease lubricated and protected against dust particles larger than 0.3mm
Features "formchromed" sprags for increased overrunning lifetime

Specifications

Product Name	CSK Washing Machine Clutch
Model	CSK25
Material	GCr15
Inner Diameter	25mm
Outer Diameter	52mm
Overrunning Speed	5200r/min
Torque Capacity	85Nm
Weight	0.12kg
Package	Tube / Carton Box / Wooden box
Payment Terms	TT, L/C, D/A, D/P, Western Union
Delivery Time	2-4 days for samples, 7 days for bulk orders

Technical Data

Type	Size (mm)	Bearing Series	Torque (Nm)	Max Speed (r/min)	Outer Diameter (mm)	Width (mm)	Dynamic Load (kN)	Static Load (kN)	Weight (kg)	Drag Torque (Ncm)
CSK(KK)	8*	-	2.5	15000	22	9	3.28	0.86	0.015	0.5

Product Images

Production Process

Frequently Asked Questions

How do you pack the goods?

Small Items: Each in small white box or Roll Pack or Tube pack - in 19x18x9CM carton box - 29*28*19CM carton box - Wooden box / Wooden pallet
Medium Items: 29*28*19cm carton box + Wooden box /Wooden pallet
Heavy Items: Wooden Box / Wooden Pallet

Can I get samples from you?

Yes, we highly encourage customers to request samples for quality verification.

Can you promise to deliver the goods on time?

Small items: In stock
Medium Items: 10-15 Days
Big items: 20-25 Days
