AS10 TSS10 NSS10 One Way Bearing 10mm Bore Roller Clutch

Name: AS10 TSS10 NSS10 One Way Bearing 10mm Bore Roller Clutch
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: AS10 TSS10 NSS10
Price: 7.10 USD
Availability: InStock

Rincian produk

Tempat asal: Jiangsu, Cina

Nama merek: SUMA

Nomor model: AS10 TSS10 NSS10

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 10

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            10mm bore one way bearing, roller clutch one way bearing, AS10 TSS10 NSS10 bearing


Ukuran Bore:	10 - 10.001 mm	Peringkat presisi:	P6
Jumlah baris:	Baris tunggal	Jenis:	Jarum, jenis rol
Tipe Segel:	Tertutup	Berat:	0,03kg
Bahan:	GCR15	Kecepatan overrunning:	3500 min-1
Kecepatan Max:	5200 min-1	Torsi seret:	0,36 ncm
Diameter luar:	30 mm	Diameter dalam:	25,9 mm
Panjang:	9 mm	Ketidaksejajaran Aksial:	± S/2
Kapasitas torsi:	6,8 nm

Ukuran Bore:	10 - 10.001 mm
Peringkat presisi:	P6
Jumlah baris:	Baris tunggal
Jenis:	Jarum, jenis rol
Tipe Segel:	Tertutup
Berat:	0,03kg
Bahan:	GCR15
Kecepatan overrunning:	3500 min-1
Kecepatan Max:	5200 min-1
Torsi seret:	0,36 ncm
Diameter luar:	30 mm
Diameter dalam:	25,9 mm
Panjang:	9 mm
Ketidaksejajaran Aksial:	± S/2
Kapasitas torsi:	6,8 nm

Deskripsi

AS10 TSS10 NSS10 One Way Bearing 10mm Bore Roller Clutch

One Way Bearing AS10 TSS10 NSS10 Roller Bearing Freewheel Clutch

Product Specifications

Attribute	Value
Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction works, Energy & Mining
Bore Size	10 - 10.001 mm
Precision Rating	P6
Number of Row	Single row
Type	Needle, roller type
Seals Type	Sealed
Model	AS10 TSS10 NSS10
Weight	0.03kg
OEM	Accept
Delivery	10-15 days
Package	Single box or as your requirements
Port	Shanghai; Ningbo
Material	Gcr15

Product Overview

The AS10 TSS10 NSS10 is a roller-type freewheel bearing designed for industrial applications. This non-bearing supported unit requires separate bearings to handle axial and radial loads, with external lubrication and sealing provisions.

Technical Features

Nominal outside dimensions compatible with series 62 ball bearings
Inner race keyed to the shaft (except 6mm bore)
Outer race features positive r6 tolerance for press fit in H7 housing
Designed to withstand axial misalignment of ± S/2 between inner and outer races
Requires rigid housing to prevent expansion after assembly

Performance Specifications

Type	Size	Overrunning speeds	Weight	Drag torque
AS (TSS)	dH7 [mm]	TKN1) [Nm]	nimax2) [min-1]	namax3) [min-1]
6	2.1	5000	7500	0.18
8	3.8	4300	6500	0.24
10	6.8	3500	5200	0.36
12	13	3200	4800	0.48
15	14	2800	4300	0.7
20	40	2200	3300	1.4
