ASNU80 One Way Clutch Roller Bearing for Industrial Fans

Name: ASNU80 One Way Clutch Roller Bearing for Industrial Fans
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: Asnu 80
Price: 7.10 USD
Availability: InStock

Rincian produk

Tempat asal: Jiangsu, Cina

Nama merek: SUMA

Nomor model: Asnu 80

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 1

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            one way clutch bearing for industrial fans, industrial fan roller bearing with warranty, one way bearing for industrial equipment


Jenis:	Sprang	Peringkat presisi:	P6
Tipe Segel:	Tertutup	Struktur:	Jenis rol
Bahan:	GCR15	Model:	Asnu80
Diameter dalam:	80mm	Diameter luar:	170mm
Kapasitas torsi:	3275nm	Berat:	6.09kg
Kecepatan maks yang berlebihan:	850 Min-1	Min kecepatan yang berlebihan:	550 Min-1
Torsi seret:	180 ncm	Bantalan Didukung:	TIDAK
Diperlukan pelumasan:	Ya

Jenis:	Sprang
Peringkat presisi:	P6
Tipe Segel:	Tertutup
Struktur:	Jenis rol
Bahan:	GCR15
Model:	Asnu80
Diameter dalam:	80mm
Diameter luar:	170mm
Kapasitas torsi:	3275nm
Berat:	6.09kg
Kecepatan maks yang berlebihan:	850 Min-1
Min kecepatan yang berlebihan:	550 Min-1
Torsi seret:	180 ncm
Bantalan Didukung:	TIDAK
Diperlukan pelumasan:	Ya

Deskripsi

ASNU80 One Way Clutch Roller Bearing for Industrial Fans

ASNU80 Cam Clutch One Way Clutch Roller Bearing for Fan

Product Specifications

Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works, Energy & Mining
Type	SPRAG
Precision Rating	P6
Seals Type	Sealed
Product Name	One Way Clutch Roller Bearing
Bearing Supported	No
Stock	Rich
OEM	Accept
Delivery Time	5-7 days after order is confirmed
Package	Wooden package or customizable
Structure	Roller type
Material	GCr15

Key Features

Roller type freewheel non-bearing supported
Requires separate bearings to support axial and radial loads
Lubrication and sealing provided by installation
Inner race keyed to the shaft
Outer race has positive n6 tolerance for press fit in H7 housing

Technical Parameters

Product Name	One Way Clutch Bearing
Model	ASNU80
Material	Chrome steel GCr15
Inner Diameter	80mm
Outer Diameter	170mm
Torque Capacity	3275Nm
Weight	6.09kg
Package	Carton Box / Wooden box
Payment Terms	TT, L/C, D/A, D/P, Western Union
Delivery Time	2-4 days for sample, 7 days for bulk orders

Performance Specifications

ASNU80 Model Highlighted: 3275Nm torque capacity, 550-850 overrunning speeds, 170mm outer diameter, 6.09kg weight

Product Images

Manufacturer Information

Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) specializes in producing various cam clutches, one way bearings, backstop clutches, and overrunning clutches with high technology.

We follow "Best Quality, Best Price, Fast Delivery, Best Service" to satisfy all customers.

Production Process

Client Visits

Frequently Asked Questions

How do you pack the goods?

Total less than 25 KG: Each in white box + 19*18*9cm box + 29*28*19CM carton box
Total Weight over 100KG: Carton box + Wooden Box / Wooden Pallet

Can I get samples from you?

We highly encourage requesting samples for quality inspection.

Can you promise timely delivery?

Small items: In stock
Medium Items: 10-15 Days
Big items: 20-25 Days
